型号
（Part Number)
|
中心频率
(Center Frequency)
(MHz)
|
带宽
（Bandwidth)
(MHz)
|
插入损耗
Insertion Loss
(dB)
|
带内波动
（Ripple in BW)
(dB)
|
驻波比
VSWR In BW
Ratio
|
带外抑制
Attenuation
dB
|
温度范围
Operation Temperation Range
℃
|
阻抗
In/Out Impendance
|
尺寸
Size
mm
|
| CCD831F12/876F12A |
831.2 |
12.5 |
1.6 max |
0.7 max |
1.5 max |
80.0 dB min @825~835 MHz |
-20 ~ +55 |
50 Ω |
176×62×46
|
| 876.2 |
80.0 dB min @870~880 MHz |
| 50.0 dB min @1200~3000 MHz |
| CCD831F12/876F12B |
831.2 |
12.5 |
2.3 max |
1.5 max |
1.5 max |
80.0 dB min @825~835 MHz |
-20 ~ +55 |
50 Ω |
100×40×85 |
| 876.2 |
80.0 dB min @870~880 MHz |
| 50.0 dB min @1200~3000 MHz |
| CCD831F12/876F12C |
831.2 |
12.5 |
1.6 max |
0.7 max |
1.5 max |
90.0 dB min @825~835 MHz |
-20 ~ +55 |
50 Ω |
198×62×36 |
| 90.0 dB min @870~880 MHz |
| 876.2 |
50.0 dB min @1200~3000 MHz |
| CCD900F30/945F30A |
900.0 |
30.0 |
1.3 max |
0.7 max |
1.5 max |
70.0 dB min @922.0 MHz |
-20 ~ +65 |
50 Ω |
185×165×50 |
| 80.0 dB min @930~960 MHz |
| 945.0 |
80.0 dB min @885~915 MHz |
| CCD902F25/947F25B |
902.5 |
25.0 |
1.5 max |
1.0 max |
1.5 max |
20.0 dB min @870~885 MHz |
-20 ~ +65 |
50 Ω |
223×62×40 |
| 55.0 dB min @925 MHz |
| 90.0 dB min @935~960 MHz |
| 947.5 |
70.0 dB min @825~837.5 MHz |
| |
| CCD902F25/947F25D |
902.5 |
25.0 |
2.2 max |
1.5 max |
1.5 max |
80.0 dB min @870~885 MHz
|
-20 ~ +55 |
50 Ω |
199×126×46 |
|
80.0 dB min @825~835 MHz
|
| 947.5 |
1.0 max |
0.7 max |
80.0 dB min @1200~3000 MHz
|
| CCD1950F60/2140F60D |
1950.0 |
60.0 |
1.3 max |
1.0 max |
1.5 max |
80.0 dB min @2110~2170 MHz |
-20 ~ +55 |
50 Ω |
150×121×35 |
|
80.0 dB min @1920~1980 MHz
|
| 2140.0 |
120.0dBc min(2×43dBm) |
